Grundfos 16S078 Multistage Submersible Pump with a Rated Flow of 17.6 US GPM, a Rated Head of 161 Ft and Stainless Steel Construction

Model: G10010008
|
Item: bci1687375

$773.00
Special Order
placeholder
Free Shipping!
Leaves the Warehouse in 6 to 10 weeks
-
Return & Shipping Details

Details

16S078 Multistage Submersible Pump with a Rated Flow of 17.6 US GPM, a Rated Head of 161 Ft and Stainless Steel Construction

16S078 Multistage submersible pump for raw water supply, groundwater lowering and pressure boosting. The pump is suitable for pumping clean, thin, non-aggressive liquids without solid particles or fibers. The pump is made entirely of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301 and suitable for horizontal and vertical installation. The pump is fitted with a built-in non-return valve.

Technical:

  • Speed for pump data: 3450 rpm
  • Rated flow: 17.6 US gpm
  • Rated head: 161 ft

Material:

  • Pump: Stainless steel
  • Pump: DIN W.-Nr. 1.4301
  • Pump: AISI 304
  • Impeller: Stainless steel
  • Impeller: DIN W.-Nr. 1.4301
  • Impeller: AISI 304

Installation:

  • Pump outlet: 1 1/4" NPT
  • Motor diameter: 4 inch

Liquid:

  • Maximum liquid temperature: 104 °F

Electrical Data:

  • Power (P2) required by pump: 1.17 HP
  • Start. method: direct-on-line
Additional Grundfos Links

Manufacturer Resources

Specification Sheet

Dimensions and Measurements

Height
12.75 in.
Product Weight
8.08 lbs.
Width
4 in.

Dimensions and Measurements

Height
12.75 in.
Product Weight
8.08 lbs.
Width
4 in.

Characteristics and Features

Material
Stainless Steel

Characteristics and Features

Material
Stainless Steel
