Grundfos SP 601 Multistage Submersible Pump with a Rated Flow of 299 US GPM, a Rated Head of 29.5 Ft and Stainless Steel Construction
Model: G14B73501|Item: bci1687667
Details
SP 601 Multistage Submersible Pump with a Rated Flow of 299 US GPM, a Rated Head of 29.5 Ft and Stainless Steel Construction
SP 601 Multistage submersible pump for raw water supply, groundwater lowering and pressure boosting. The pump is suitable for pumping clean, thin, non-aggressive liquids without solid particles or fibers. The pump is made entirely of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301 and suitable for horizontal and vertical installation. The pump is fitted with a built-in non-return valve. The motor is a 3 phase motor of the canned type with a sand shield, liquid lubricated bearings and pressure equalizing diaphragm.
Technical:
- Speed for pump data: 3450 rpm
- Rated flow: 299 US gpm
- Rated head: 29.5 ft
- Shaft seal for motor: HM/CER
- Approvals on nameplate: CE,GOST2,CSA
- Curve tolerance: ISO9906
Material:
- Pump: Stainless steel
- Pump: DIN W.-Nr. 1.4301
- Pump: AISI 304
- Impeller: Stainless steel
- Impeller: DIN W.-Nr. 1.4301
- Impeller: AISI 304
- Motor: Stainless steel
- Motor: DIN W.-Nr. 1.4301
- Motor: AISI 304
Installation:
- Pump outlet: 3" NPT
- Motor diameter: 4 inch
Electrical Data:
- Motor type: MS4000
- Rated power - P2: 4.96 HP
- Main frequency: 60 Hz
- Rated voltage: 3 x 440-460 V
- Start. method: direct-on-line
- Service factor: 1,15
- Rated current: 8,65-8,65 A
- Cos phi - power factor: 0,83-0,80
- Rated speed: 3460-3470 rpm
- Enclosure class (IEC 34-5): 58
Manufacturer Resources
Specification SheetDimensions and Measurements
Height | 33.9 in. |
Product Weight | 74.5 lbs. |
Width | 5.75 in. |
Dimensions and Measurements
Height | 33.9 in. |
Product Weight | 74.5 lbs. |
Width | 5.75 in. |
Characteristics and Features
Material | Stainless Steel |
Characteristics and Features
Material | Stainless Steel |
Electrical and Operational Information
Frequency | 60 Hertz |
Electrical and Operational Information
Frequency | 60 Hertz |
