Grundfos 5S1531 Multistage Submersible Pump with a Rated Flow of 4.4 US GPM, a Rated Head of 528 Ft and Stainless Steel Construction

Model: G8110031
|
Item: bci1688208

$3,278.00
Special Order
placeholder
Free Shipping!
Leaves the Warehouse in 5 to 10 weeks
-
Return & Shipping Details

Details

5S1531 Multistage Submersible Pump with a Rated Flow of 4.4 US GPM, a Rated Head of 528 Ft and Stainless Steel Construction

5S1531 Multistage submersible pump for raw water supply, groundwater lowering and pressure boosting. The pump is suitable for pumping clean, thin, non-aggressive liquids without solid particles or fibers. The pump is made entirely of Stainless steel DIN W.Nr. DIN W.Nr. 1.4301 and suitable for horizontal and vertical installation. The pump is fitted with a built-in non-return valve.

Technical:

  • Speed for pump data: 3450 rpm
  • Rated flow: 4.4 US gpm
  • Rated head: 528 ft

Material:

  • Pump: Stainless steel
  • Pump: DIN W.-Nr. 1.4301
  • Pump: AISI 304
  • Impeller: Stainless steel
  • Impeller: DIN W.-Nr. 1.4301
  • Impeller: AISI 304

Installation:

  • Pump outlet: 1" NPT
  • Motor diameter: 4 inch

Liquid:

  • Maximum liquid temperature: 104 °F

Electrical Data:

  • Power (P2) required by pump: 1.97 HP
  • Start. method: direct-on-line
Additional Grundfos Links

Manufacturer Resources

Specification Sheet

Dimensions and Measurements

Height
33.563 in.
Product Weight
27 lbs.
Width
4 in.

Dimensions and Measurements

Height
33.563 in.
Product Weight
27 lbs.
Width
4 in.

Characteristics and Features

Material
Stainless Steel

Characteristics and Features

Material
Stainless Steel
