Grundfos CR 201 AGJAV HQQV Vertical, Non-self Priming, Multistage, Inline, Centrifugal Pump with a Maximum Temperature of 194°F, a Rated Flow of 111 US GPM, a Rated Head of 49.5 Ft and Cast Iron Construction

Model: G96523959
|
Item: bci1690614

$4,506.00
Special Order
placeholder
Free Shipping!
Leaves the Warehouse in 6 to 10 weeks
-
Return & Shipping Details

Details

CR 201 AGJAV HQQV Vertical, Non-self Priming, Multistage, Inline, Centrifugal Pump with a Maximum Temperature of 194°F, a Rated Flow of 111 US GPM, a Rated Head of 49.5 Ft and Cast Iron Construction

CR 201 AGJAV HQQV Vertical, non-self priming, multistage, inline, centrifugal pump for installation in pipe systems and mounting on a foundation.

Technical:

  • Speed for pump data: 3457 rpm
  • Rated flow: 111 US gpm
  • Rated head: 49.5 ft
  • Shaft seal: HQQV
  • Approvals on nameplate: NEMA

Material:

  • Pump housing: Cast iron
  • Pump housing: EN-JL1030
  • Pump housing: ASTM A48-30 B
  • Impeller: Stainless steel
  • Impeller: DIN W.-Nr. 1.4301
  • Impeller: AISI 304

Installation:

  • Maximum ambient temperature: 104 °F
  • Max pressure at stated temperature: 232 psi / 194 °F
  • Max pressure at stated temperature: 232 / -4 psi/°F
  • Flange standard: ANSI
  • Pipe connection: 2"
  • Pressure stage: Class 250
  • Flange size for motor: 182TC

Liquid:

  • Liquid temperature range: -4 .. 194 °F

Electrical Data:

  • Motor type: BALDOR
  • Number of poles: 2
  • Rated power - P2: 2.95 HP
  • Power (P2) required by pump: 2.95 HP
  • Main frequency: 60 Hz
  • Rated voltage: 1 x 115/208-230 V
  • Service factor: 1,15
  • Rated current: 29/16-14,5 A
  • Rated speed: 3450 rpm
  • Motor efficiency at full load: 75 %
Additional Grundfos Links

Manufacturer Resources

Specification Sheet

Dimensions and Measurements

Depth
10.125 in.
Height
31.61 in.
Product Weight
162 lbs.
Width
11.87 in.

Dimensions and Measurements

Depth
10.125 in.
Height
31.61 in.
Product Weight
162 lbs.
Width
11.87 in.

Characteristics and Features

Material
Cast Iron

Characteristics and Features

Material
Cast Iron

Electrical and Operational Information

Frequency
60 Hertz

Electrical and Operational Information

Frequency
60 Hertz
