Item # bci3260418
Item # bci3260418
Juno Lighting IC23 Medium (E26) IC Rated New Construction Housing From the Contractor Select Collection
Model:IC23 W
$10.76
10000 In Stock
Free Shipping on orders over $49.00!
Leaves the Warehouse in 1 to 3 business days
-Details
Features
- Includes push in electrical connectors for easy installation
- Integral T-bar notch and clip secures housing - no additional clips required
- Included Floating socket with spring attaches to trim for easy installation. Integral T-bar notch and clip secures housing in suspended ceiling grid –no accessory clips required
- Can only be used with select trims - see specification sheet
- Airtight when paired with select trims
- Insulated ceiling rated and airtight
- Constructed from aluminum
- Manufactured in America
- Requires (1) 90 watt medium (E26) bulb
- UL and CUL rated for damp locations
Dimensions
- Height: 7-1/8"
- Width: 13-1/8"
- Depth: 13-1/2"
- Product Weight: 2.5 lbs
- Cutout Size: 6-7/8 Inches
Electrical Specifications
- Bulb Base: Medium (E26)
- Number of Bulbs: 1
- Bulb Included: No
- Watts Per Bulb: 90 watts
- Wattage: 90 watts
- Voltage: 120 volts
Dimensions and Measurements
Cutout Size | 6.875 in. |
Depth | 13.5 in. |
Height | 7.1 in. |
Product Weight | 2.5 lbs. |
Width | 13.1 in. |
Dimensions and Measurements
Cutout Size | 6.875 in. |
Depth | 13.5 in. |
Height | 7.1 in. |
Product Weight | 2.5 lbs. |
Width | 13.1 in. |
Included Components
Bulb Included | No |
Included Components
Bulb Included | No |
Characteristics and Features
Airtight | Yes |
Bulb Base | Medium (E26) |
Bulb Visible | No |
Housing Type | New Construction Housing |
Light Direction | Down Lighting |
Material | Aluminum |
Number of Bulbs | 1 |
Number of Light Source(s) | 1 |
Characteristics and Features
Airtight | Yes |
Bulb Base | Medium (E26) |
Bulb Visible | No |
Housing Type | New Construction Housing |
Light Direction | Down Lighting |
Material | Aluminum |
Number of Bulbs | 1 |
Number of Light Source(s) | 1 |
Electrical and Operational Information
Power Source | Hardwired |
Voltage | 120 |
Voltage Type | Line Voltage (110-120V) |
Wattage | 90 |
Watts Per Bulb | 90 |
Electrical and Operational Information
Power Source | Hardwired |
Voltage | 120 |
Voltage Type | Line Voltage (110-120V) |
Wattage | 90 |
Watts Per Bulb | 90 |
Warranty and Product Information
Approved for Commercial Use | Yes |
Certifications | UL |
Collection | IC23 |
Country Of Origin | USA |
IC Rating | IC |
Location Rating | Damp Location |
Made in America | Yes |
Warranty and Product Information
Approved for Commercial Use | Yes |
Certifications | UL |
Collection | IC23 |
Country Of Origin | USA |
IC Rating | IC |
Location Rating | Damp Location |
Made in America | Yes |
