Schlage Sutton Exterior Only Sectional Single Cylinder Keyed Entry Handleset from the J Series

Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys

Single Cylinder Keyed Entry (Exterior Only): Exterior only single cylinder handlesets feature the exterior trim of a working mechanical lock set, and require an associated interior pack for full installation. Single cylinder handlesets lock and unlock from the exterior with a key, and from the interior with an associated thumb turn.

Features:

• BHMA grade 3 certified security
• Constructed of high quality materials for lasting durability
• Installs easily with all necessary mounting hardware included
• Covered by a limited lifetime mechanical and limited 5 year finish warranty
• Complies with ADA standards
• Exterior portion only, pair with JH59 interior pack

Specifications:

• Backset: Adjustable 2-3/8" or 2-3/4"
• Cross Bore: 2-1/8"
• Edge Bore: 1"
• Door Thickness: 1-3/8" to 1-3/4"
• Handing: Reversible Left or Right
• Cylinder: 5 Pin C
• Material: Zinc
• Mounting Center to Center: 5-1/2"
• Overall Height: 16-1/4"
• Handle Projection: 2-1/4"
• Trim Height: 16-1/4"
• Trim Width: 2-7/16"
