The Zephyr AK8100AS-BF has been discontinued
** See similar or replacement items below **
Item # bci4255320
Zephyr Tornado I 200 - 600 CFM 28 Inch Wide Insert Range Hood with Hybrid Baffle Filters
Model: AK8100AS-BF|Item: bci4255320
from theTornado I Collection
Discontinued
We still have product details and accessories, scroll down to see them!
Discontinued
We still have product details and accessories, scroll down to see them!
Details
This 600 CFM power pack features dual-level halogen lighting, 3 speed blower, a hybrid baffle filter and an angled housing unit for a better fit with any built-in canopy. An adjustable depth liner is also available.
Features:
- Blower outputs up to 600 CFM to keep your kitchen free of cooking fumes and odors
- Hybrid baffle filters utilize stainless steel baffles for an improved aesthetic and aluminum mesh for efficient filtration
- 3 speed mechanical slide controls allow you to easily set the power level of your range hood
- Dual-level halogen lighting illuminates cooking area
- Optional liner accessories available
- Covered under a 1 year labor and 10 year parts warranty
Product Technologies:
- Optional Ductless Recirculating Kit: Ductless recirculating kit used when venting air outside your home is not possible. Smoke and odors pass through charcoal filters allowing purified air to be reintroduced into the kitchen
Specifications:
- CFM: 200, 600
- Sones: 1.4, 6
- Nominal Width: 28"
- Width: 27-9/16"
- Height: 10-1/2"
- Depth: 11-3/16"
- Duct Size: 6" Round
- Ceiling Height: 96" - 144"
- Amperage: 3.3A
- Voltage: 120V
- Wattage: 396W
Dimensions and Measurements
Ceiling Height (Max) | 144 in. |
Ceiling Height (Min) | 96 in. |
CFM | 200, 600 |
Depth | 11.188 in. |
Duct Size | 6" Round |
Height | 10.5 in. |
Height Above Cooktop | 24" to 36" |
Nominal Width | 28 in. |
Product Weight | 20.3 lbs. |
Width | 27.5625 in. |
Dimensions and Measurements
Ceiling Height (Max) | 144 in. |
Ceiling Height (Min) | 96 in. |
CFM | 200, 600 |
Depth | 11.188 in. |
Duct Size | 6" Round |
Height | 10.5 in. |
Height Above Cooktop | 24" to 36" |
Nominal Width | 28 in. |
Product Weight | 20.3 lbs. |
Width | 27.5625 in. |
Included Components
Available Without Blower | No |
Bulb Included | Yes |
Convertible to Ductless / Recirculating | No |
Ductless | No |
Includes Remote | No |
Light Included | Yes |
Included Components
Available Without Blower | No |
Bulb Included | Yes |
Convertible to Ductless / Recirculating | No |
Ductless | No |
Includes Remote | No |
Light Included | Yes |
Characteristics and Features
Blower Type | Internal |
Bulb Type | Halogen |
Control Type | Slide |
Duct Discharge | Vertical |
Filter Type | Baffle Filters |
Installation Type | Full Installation |
Material | Stainless Steel |
Number of Bulbs | 2 |
Panel Ready | No |
Smart Home | No |
Characteristics and Features
Blower Type | Internal |
Bulb Type | Halogen |
Control Type | Slide |
Duct Discharge | Vertical |
Filter Type | Baffle Filters |
Installation Type | Full Installation |
Material | Stainless Steel |
Number of Bulbs | 2 |
Panel Ready | No |
Smart Home | No |
Electrical and Operational Information
Amperage | 3.3 |
Sones | 1.4, 6 |
Speeds | 3 |
Voltage | 120 |
Wattage | 396 |
Watts Per Bulb | 35 |
Electrical and Operational Information
Amperage | 3.3 |
Sones | 1.4, 6 |
Speeds | 3 |
Voltage | 120 |
Wattage | 396 |
Watts Per Bulb | 35 |
Warranty and Product Information
ADA | No |
Approved for Commercial Use | No |
Collection | Tornado I |
Country Of Origin | Taiwan |
Energy Star | No |
Manufacturer Warranty | 1 Year Labor, 10 Year Parts |
Outdoor Approved | No |
Title 24 | Yes |
Warranty and Product Information
ADA | No |
Approved for Commercial Use | No |
Collection | Tornado I |
Country Of Origin | Taiwan |
Energy Star | No |
Manufacturer Warranty | 1 Year Labor, 10 Year Parts |
Outdoor Approved | No |
Title 24 | Yes |
